26800 Lithium Battery
26800-5Ah LiFePO4 Cell
●Pressure-resistant nickel-plated steel shell
●High capacity
●Excellent cycle life
●Excellent high and low-temperature performance
●Voltage output is stable
●Small self-discharge
●High vibration and shock resistance
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
This 26800 lithium battery has comprehensive safety protection functions, such as overcharge, overdischarge, overcurrent, overtemperature, short circuit, etc., and has a balancing function to effectively improve battery life.
Specification
|
Item |
Condition/ Note |
Specification |
Remark |
|
Norminal Capacity |
0.5C discharge capacity |
5Ah |
|
|
AC Impedance |
At AC 1000 Hz |
≤15mΩ |
|
|
Nominal Voltage |
|
3.2V |
|
|
Cell Size |
Cell Diameter |
26.22±0.3mm |
|
|
Cell Height |
81.00±0.2 mm |
|
|
|
Cell Weight |
|
112±2g |
|
|
End-of-charge Voltage |
CC Mode |
3.65V |
|
|
End-of-charge Current |
CV Mode |
0.15A |
|
|
Charging Method |
Standard Charging |
0.5C at CC/CV |
|
|
Max Continuous Charging |
1C at CC/CV |
|
|
|
End-of-discharge Voltage |
CC Mode |
2.0V |
|
|
Max continuous Discharging Current |
|
5A |
|
|
Max Pulse Discharging Current |
|
10.2A |
5s |
|
Cycle Life |
0.5C/100% DOD25℃±2℃ |
≥2000 cycles |
|
|
Charging Temperature |
|
0-60℃ |
|
|
Discharging Temperature |
|
-20-60℃ |
|
Application
A single 26800 lithium battery cell is assembled into a battery pack of a certain specification according to the specific application
1) Energy storage: UPS, backup, power station.
2) Electric vehicles: golf carts, electric scooters.
3) Solar system, wind energy storage, solar/energy storage home system, solar street light.
4) Telecom base stations.
OEM/ODM
We have a professional lithium-ion battery design and manufacturing background;
We have our own mature freight forwarding team, and the backup freight is more competitive;
Factory direct sales, we can provide all kinds of batteries you need with competitive price and high quality.
Warnning
- Do not over discharge/over charge
- Recharge a depleted battery as quickly as possible
- Don't short circuit
- Do not throw into fire
- Do not expose to extreme heat or water
- Please familiarize yourself with how to dispose of lithium-ion batteries before purchasing.
