26650 LiFePO4 Cells
26650-3.0Ah LiFePO4 Cell
●Pressure-resistant nickel-plated steel shell
●High capacity
●Excellent cycle life
●Excellent high and low temperature performance
●Voltage output is stable
●Small self-discharge
●Double security protection
●High vibration and shock resistance
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product details
1、Comes with explosion-proof valve
The 26650 LiFePO4 Cells itself has its own explosion-proof valve, which has high safety performance, no explosion, no combustion, high-temperature resistance, good performance, and overcharge resistance.
2. Quality Assurance, High-quality Class A batteries, high capacity, low internal resistance, and can be discharged with large currents;
3. Long service life,Stable performance and long cycle life;
4. High safety performance
No memory effect: can be used for charging and discharging at any time
High safety performance: overcharge and overdischarge protection
5. Perfect service
Short delivery time, reasonable price, perfect service
LOGO can be sprayed and the color of the outer skin can be changed according to customer needs
Specification
|
Item |
Condition/ Note |
Specification |
Remark |
|
Norminal Capacity |
0.2C discharge capacity |
3.0Ah |
|
|
AC Impedance |
At AC 1000 Hz |
≤15mΩ |
|
|
Nominal Voltage |
|
3.2V |
|
|
Cell Size |
Cell Diameter |
26.22±0.3mm |
|
|
Cell Height |
67.10±0.2 mm |
|
|
|
Cell Weight |
|
83.0±3.0g |
|
|
End-of-charge Voltage |
CC Mode |
3.65V |
|
|
End-of-charge Current |
CV Mode |
0.15A |
|
|
Charging Method |
Standard Charging |
0.2C at CC/CV |
300min |
|
Max Continuous Charging |
1C at CC/CV |
60min |
|
|
End-of-discharge Voltage |
CC Mode |
2.0V |
|
|
Max continuous Discharging Current |
|
3.0A |
|
|
Max Pulse Discharging Current |
|
9.0A |
5s |
|
Cycle Life |
1C/100% DOD25℃±2℃ |
≥2000 cycles |
|
|
Charging Temperature |
|
0-60℃ |
|
|
Discharging Temperature |
|
-20-60℃ |
|
Advantage
1. Quality-guaranteed original battery. Large-scale, mechanized production, high quality. High-temperature resistance, low-temperature resistance, corrosion resistance, stable battery performance.
2. Safe and explosion-proof. The battery has high safety performance, no explosion, no pollution and combustion; non-toxic, no pollution, low internal resistance, reduced battery self-discharge, and extended use time.
3. OEM is welcome. Source manufacturers, power, capacity, voltage, length, width, circuit board, etc. can be customized, welcome to sample custom processing to meet your various needs
4. Wide range of applications. 26650 LiFePO4 Cells are widely used in lithium battery packs such as DIY electric vehicles, motorcycles, electric three-wheelers, and electric four-wheelers. It can also assemble inverter batteries, headlights, model airplanes, mobile power supplies, energy storage, solar lights, external power supplies, etc.
5. Worry-free after-sales service. Strictly control every detail, carry out effective sampling inspection on each batch of finished products, and pursue zero defects. If you have any questions, please contact us.
Warning
1. Do not insert batteries with (+) and (-) reversed.
2. Do not submerge the battery in the water.
3. Do not disassemble, dispose in fire, heat or short-circuit.
4. Do not expose batteries to sunlight for a long time.
5. Do not trample the battery with a hammer.
6. Do not keep batteries close to the baby.
